Ball screw with nut SFU1604 1000mm

ZAR 1,093.65 ZAR 951.00

In stock

SKU

CNC-0026-P02

Description:

A Ball screw with nut SFU1604 1000mm is a linear motion component that transforms rotational motion into precise linear motion.
The designation "SFU1604" indicates a 16mm diameter ball screw with a 4mm lead, meaning the nut travels 4mm for each full rotation of the screw.
The "1000mm" specifies the total length of the ball screw, making it suitable for applications requiring longer linear travel, such as in CNC machines and 3D printers.

Model number: SFU1604
Screw diameter: 16mm
Lead: 4mm (distance traveled by the nut per rotation)
Screw length: 1000mm
Nut type: Single ball nut
Material: Hardened steel for high durability and wear resistance
Precision grade: Typically C7 or C5, indicating precision levels
Ball nut outer diameter: ~28-30mm
Efficiency: Generally over 90%, due to low-friction ball bearings
Load capacity: Moderate load handling capability
Preload: Optional, can be configured to reduce backlash
Sealing: Rubber seals to prevent dust and debris contamination
Application: Ideal for CNC machines, 3D printers, and other automated systems for accurate linear movement
