THERMOSTAT 70DEG C SPST-NC CYL, CS707025Y
Description:
- The CS707025Y Thermostat is a dependable and efficient mechanical thermostat intended for industrial use.
- It uses a Single Pole Single Throw Normally Closed (SPST-NC) circuit, which keeps the circuit closed until the temperature hits 70°C.
- This thermostat is perfect for temperature management in a variety of industrial environments, delivering accurate and reliable results.
Specifications:
- Circuit: SPST-NC.
- Switching Temperature: 158°F (70°C).
- Current Rating – AC: 10A (250V), 15A (125V).
- Current Rating – DC: 10A (24V), 15A (12V).
- Tolerance: ±9°F (±5°C).
- Switching Cycles: 100K.
- Termination Style: Quick Connect.
- Mounting Type: Chassis Mount.
