EDAC 516 D-sub Connector Socket (100pcs)
Description:
The terminal contact for the EDAC 516 series is a female crimp contact. With a current rating of 8.5A, the connector body orientation of contact is straight. Phosphor bronze is the contact material, while gold over nickel is the contact plating. The temperature range for operation is -65°C to 105°C.
Specifications:
- Gender: Female
- Body Orientation: Straight
- Termination Method: Crimp
- Current Rating: 8.5A
- Series: 516
- Contact Plating: Gold over Nickel
- Contact Material: Phosphor Bronze
- Minimum Operating Temperature: -65°C
- Maximum Operating Temperature: +125°C
| SKU | Con1-0057-000 |
|---|
