Finger Push Micro Switch (RED)
Description:
- A Finger Push Micro Switch (Red) is a small, momentary push button switch with a red LED that turns on when pressed.
- Compact size: Ideal for applications where space is restricted.
- Ease of Use: Operate with a single press.
- Visual Feedback: The red LED clearly indicates that the switch has been activated.
- Durability: Designed for extended use with little wear and tear.
Specifications:
- Model: Finger Push Micro Switch (Red).
- Material: Stainless steel housing, metal contacts.
- Button Colour: Red LED.
- Switch Type: Momentary (Push On/Release Off).
- Contact Rating: Up to 3A at 36V.
- Contact Resistance: Less than 1 ohm when closed.
- Insulation Resistance: Greater than 100M ohms at 500V DC.
- Operating Voltage: 12V.
- Button Diameter: 12mm.
- Connector Type: 4-pin.
- Waterproof Rating: IP67 (waterproof and dustproof).
- Dimensions: Length: 21.3mm, Width: 14mm.
- Lifespan: Up to 100,000 cycles.
- Features: Anti-static, oil-resistant, durable design.
