HAGER C/BREAKER 2POLE 10AMP 6KA

ZAR 527.39 ZAR 458.60

In stock

SKU

CBI-0013-H08

Description:

The Hager 2-Pole 10A 6kA Circuit Breaker is a compact miniature circuit breaker (MCB) designed to provide reliable protection against overloads and short circuits in residential, commercial, and light industrial electrical installations. With its double-pole isolation and C-curve tripping characteristic, it ensures both safety and stability in circuits with moderate inrush currents.

Specifications:

Brand / Model: Hager MU210A / MA210Z (depending on region)
Type: Miniature Circuit Breaker (MCB)
Poles: 2 (double-pole protection)
Rated Current (In): 10 A
Breaking Capacity (Icn): 6 kA at 230 V AC (IEC 60898-1 standard)
Tripping Curve: C-Curve (suited for moderate inrush currents, e.g., fluorescent lighting, small motors)
Mounting: DIN rail, 2 modules wide
Dimensions: 35 mm width
Operating Temperature: Rated current varies slightly with ambient temperature (e.g., 10 A at 30°C, 9 A at 50°C)
Applications: Residential distribution boards, commercial panels, light industrial circuits
