HGH15CA Block for Linear Rail, HGR15
Description:
- The "HGH15CA bearing block" is a part that slides along an "HGR15 linear rail."
- The block contains ball bearings, allowing for smooth, precise movement along the rail.
- It's commonly used in CNC machines, 3D printers, and other equipment where accurate linear motion is needed.
- "HGH15CA" refers to the size and style of the block, while "HGR15" refers to the size (15mm wide) of the rail it fits onto.
Specifications:
- Block type: HGH (Square-type, heavy load)
- Model number: HGH15CA
- Rail size: 15mm width (HGR15)
- Load type: Heavy load
- Accuracy class: Usually available in several grades (C, H, P, SP, UP) with varying precision levels
- Block dimensions:
Length: ~83 mm
Width: ~47 mm
Height: ~30 mm - Mounting hole dimensions: 4 x M5 threads
- Number of ball circuits: 4
- Material: High-strength steel
- Sealing: Dual rubber seals for dust protection
- Operating temperature: Usually up to 80°C, depending on lubricant
- Preload options: Zero to light, medium, or heavy, depending on the application requirements
