MA316Z 16A 3P 6kA C-CURVE MCB
MA316Z 16A 3P 6kA C-CURVE MCB:
The Hager MA316Z is a 3-pole miniature circuit breaker (MCB) designed for industrial and commercial installations. It provides protection against overloads and short circuits, with a C-curve tripping characteristic suitable for circuits with moderate inrush currents, such as motors and transformers.
Specifications:
- Rated Current: 16 A
- Voltage Rating: 230/400 V AC
- Breaking Capacity: 6 kA
- Poles: 3-Pole (3P)
- Tripping Curve: C curve
- Mounting Type: DIN rail mounting
- Operating Temperature Range: -25°C to 70°C
- Standards Compliance: IEC 60947-2
- Applications: Protection for three-phase circuits, industrial machinery, and distribution systems
