MAX232N 5V RS232 Driver/Receiver 16pin
Description:
- The MAX232N is an industry-standard integrated circuit that converts signals between RS-232 serial and TTL voltage levels.
- It is commonly used in serial communication applications to connect microcontrollers or other TTL-based devices to RS-232 peripherals, such as computers, modems, and other serial devices.
Specifications:
- Supply Voltage (Vcc): +4.5V to +5.5V.
- Supply Current (Icc): 8mA.
- Input Voltage Levels (RS-232 Inputs): ±30V maximum.
- Output Voltage Swing (RS-232 Outputs): ±9V minimum at Vcc = 5V.
- Driver Output Resistance (Rout): 300Ω.
- Receiver Input Resistance (Rin): 3kΩ to 7kΩ.
- Driver Input Threshold (VT+): 2.0V minimum.
- Driver Input Threshold (VT-): 0.8V maximum.
- Receiver Output Voltage (VOH): 3.5V minimum at IOut = -1.0mA.
- Receiver Output Voltage (VOL): 0.4V maximum at IOut = 1.6mA.
- ESD Protection (Human Body Model): ±2kV.
