MC3470P Integrated Circuit 18PIN
Description:
The MC3470P is a floppy disk read amplifier designed for data retrieval from magnetic storage media. It processes the differential AC signal from the magnetic head and converts it into a digital output pulse, making it useful for floppy disk drive systems.
Specifications:
- Number of Pins: 18
- Supply Voltage:
VCC1: 4.75V to 5.25V DC
VCC2: 10V to 14V DC - Differential Voltage Gain: 80V/V to 120V/V
- Input Bias Current: -10µA to -25µF
- Common Mode Rejection Ratio: 50dB
- Bandwidth: 5MHz (-3dB)
- Output Voltage Swing: 3V to 4V
- Operating Temperature Range: 0°C to 70°C
| SKU | INC-0269-C09 |
|---|
