N8T97N Integrated Circuit 16Pin
Description:
The N8T97N is a vintage high-speed hex 3-state buffer/inverter IC, originally produced by Signetics and compatible with TTL logic levels. It was designed for bus interface applications, allowing six independent buffer/inverter channels with 3-state outputs—ideal for driving data buses in early microprocessor systems.
Specifications:
- Function: Hex 3-state buffer/inverter
- Logic Family: Schottky TTL
- Number of Gates: 6
- Inputs per Gate: 1
- Output Type: 3-state TTL-compatible
- Propagation Delay: ~8 ns
- Supply Voltage: 5 V ±5%
- Supply Current: ~65 mA total
- Control Inputs: Two enable lines (DIS1, DIS2) for grouped output control
- Package: 16-pin DIP
- Operating Temperature: 0°C to +70°C
| SKU | INC-0406-C09 |
|---|
