Description:

• This encoder employs an optical disk with 500 slots and a light source/detector pair.
• As the shaft rotates, the encoder produces 500 digital pulses every revolution, which can be counted to calculate angular position, speed, or direction.
• The wide input voltage range (5-24V) makes it suitable for a variety of control systems.
