Vishay W04G-E4/51, Bridge Rectifier, 1.5A 400V, 4-Pin WOG
Vishay W04G-E4/51, Bridge Rectifier, 1.5A 400V, 4-Pin WOG:
The Vishay W04G-E4/51 is a compact, 4-pin bridge rectifier designed for AC-to-DC conversion in low-power applications such as power adapters, small motor drives, and LED drivers. Its WOG package ensures easy mounting and integration into PCBs.
Specifications:
- Maximum Repetitive Reverse Voltage (VRRM): 400V
- Average Forward Current (IF(AV)): 1.5A
- Surge Forward Current (IFSM): 50A (8.3 ms single half sine wave)
- Forward Voltage Drop (VF): 1.1V per diode at 1.5A
- Reverse Current (IR): 5 µA at 400V
- Operating Temperature Range: -55°C to +150°C
- Storage Temperature Range: -55°C to +150°C
- Package Type: WOG, 4-pin (flat, compact design)
