Z-Stick Gen5+
Description:
The Aeotec Z-Stick Gen5 is a USB dongle that transforms any computer or compatible smart home hub into a Z-Wave controller. It's a key component for building a Z-Wave smart home network, allowing you to control Z-Wave devices from your PC, Raspberry Pi, or compatible home automation software. It's highly compatible with Z-Wave gateways, software platforms like Home Assistant, and supports local device control even when the internet is down.
Features:
- Z-Wave Controller:
Acts as a Z-Wave controller when connected to a computer or gateway. - Cross-Platform Support:
Works with Windows, macOS, Linux, and Raspberry Pi. - Battery Backup:
Allows you to unplug and include/exclude devices directly into the network without a computer, using its internal battery. - Z-Wave Plus:
Supports the latest Z-Wave Plus standard, providing extended range, faster communication, and better energy efficiency. - OTA (Over-the-Air) Updates:
Supports OTA firmware upgrades for itself and connected Z-Wave devices. - Security:
Provides AES-128 encryption for secure communication between devices. - Plug-and-Play:
Easy to set up via USB with compatible software and hubs. - Wide Compatibility:
Works with numerous Z-Wave devices from other manufacturers, allowing integration into larger networks. - Range:
Enhanced wireless range of up to 150 meters (open air) for wider coverage.
Specifications:
- Chipset:
Z-Wave Plus 500 series. - Interface:
USB 2.0. - Power Supply:
USB-powered (5V), with internal rechargeable battery for portable inclusion/exclusion. - Frequency:
Based on region (868.42 MHz for EU, 908.42 MHz for US, 921.42 MHz for AU/NZ). - Range:
Up to 150 meters (open air). - Dimensions:
7.5cm x 1.9cm x 1.0cm. - Operating Temperature:
0°C to 40°C. - Storage Temperature:
-20°C to 60°C. - Operating System Support:
Windows, macOS, Linux, Raspberry Pi. - Z-Wave Standard:
Z-Wave Plus. - Backup Battery:
Built-in rechargeable battery for device inclusion/exclusion.
Compatibility:
Works with:
- Compatible with any Z-Wave or Z-Wave Plus devices.
- Works with open-source software and home automation hubs such as Home Assistant, OpenHAB, Domoticz, etc.
